True Zero Order Waveplate

Single Plate True Zero-Order Waveplate has broad spectral bandwidth ,wide temperature bandwidth ,wide angle bandwidth,high damage threshold with standard wavelength: 1064,1310nm, 1550nm and thickness down to 0.028mm.


  • Retardation tolerance: λ/500
  • Parallelism: < 1 arc sec
  • Wavefront Distorance: <λ/10@633nm
  • Damage Threshold: >500MW/cm2@1064nm, 20ns, 20Hz (single plate)
  • Coating: AR Coating
  • Product Detail

    Single Plate True Zero-Order Waveplate has broad spectral bandwidth ,wide temperature bandwidth ,wide angle bandwidth,high damage threshold with standard wavelength: 1064,1310nm, 1550nm and thickness down to 0.028mm.
    Cemented True Zero-Order Waveplates has broad spectral bandwidth,wide temperature bandwidth,wide angle bandwidth,cemented by epoxy.
