LGS (LiGaS2) Crystal

LGS is a new type of mid-infrared nonlinear crystal. LiGaS2 has excellent properties such as wide band gap, low two-photon absorption, wide transparent range, small group velocity mismatch, high thermal conductivity, and low thermal expansion coefficient.


WhatsApp Download as PDF

Product Detail

Technical Parameter

Test Report

LGS is a new type of mid-infrared nonlinear crystal. LiGaS2 has excellent properties such as wide band gap, low two-photon absorption, wide transparent range, small group velocity mismatch, high thermal conductivity, and low thermal expansion coefficient. Its UV cutoff wavelength of about 320nm allows LGS to be pumped by visible light and all solid-state near-infrared lasers for frequency conversion. Using different nonlinear frequency conversion, the output range of mid-infrared laser sources based on LiGaS2 crystals has been continuously expanded, and the currently achievable tuning output range covers 3.0~11.5um.



Application:

OPO/OPA/DFG/SHG

Basic Properties
Chemical LiGaS2
Crystal system Orthorhombic
Space point group mm2
Lattice constant c = 6.218Å,  a = 6.513Å,  b=7.863Å
Effective light transmission range 0.32-11.6μm
Nonlinear coefficient d31≈5.8 pm/Vd24≈5.1 pm/Vd33≈-10.7 pm/V
Thermal conductivity 6-8W/m.K
Coefficient of thermal expansion αa ≈ 1.5× 10-6/K，αc≈2.0×10-6/K
Damage Threshold ＞50GW/cm2@1030nm, 300fs

7a78ddfce5f4da8e2518dde3740fce8
