Laser Flash Lamp

Generally, a Xenon lamp need to seal in a quartz glass tube of the two metal electrodes to store electrical energy, after a high vacuum tube filled with xenon gas treatment, to output the pulse light pulse discharge of the gas discharge lamp. Xenon Lamp widely used in laser engraving machine, laser welding machine, laser drilling machine, laser beauty machine. We manufacture Xenon Lamp selection of quality UV filter quartz tube as the tube material to high quality density thorium tungsten, barium, cerium tungsten electrode tungsten or xenon lamp electrodes, with a load capacity, high efficiency pump laser beam quality, long life and other characteristics.


  • Type: LASER
  • Outer Diameter/mm: 4
  • Arc Length/mm: 25
  • Total Length/mm: 38
  • Product Detail

    Dimensions

    Generally, a Xenon lamp need to seal in a quartz glass tube of the two metal electrodes to store electrical energy, after a high vacuum tube filled with xenon gas treatment, to output the pulse light pulse discharge of the gas discharge lamp. Xenon Lamp widely used in laser engraving machine, laser welding machine, laser drilling machine, laser beauty machine. We manufacture Xenon Lamp selection of quality UV filter quartz tube as the tube material to high quality density thorium tungsten, barium, cerium tungsten electrode tungsten or xenon lamp electrodes, with a load capacity, high efficiency pump laser beam quality, long life and other characteristics.
    According to the current, the lifespan is generally between 300-800 hours.
    Due to the loss of gas, the xenon lamp requires periodic replacement, which can guarantee that the machine is running at highest efficiency.
    We use high-quality quartz glass tube, the xenon lamp has high efficiency, long life, etc.
    Applications:
    • Hair removal: limbs hair, axillary hair, beard, lip hairs, etc.
    • Skin rejuvenation: remove wrinkle, whiten skin, shrink pore, remove acne, etc.
    • Speckle removal: freckle, age pigment, sunburn, birthmark, etc.
    • Vascular Lesions: telangiectasia, rosacea, spider angiomatas, etc.
    • light source for laser equipments. It is the most important consumable of machine. its quality and matching issues affect the performance and quality of laser equipment directly. Nd: YAG pulsed xenon lamp is widely used in laser engraving machine, laser welding machine, laser drilling machine, laser beauty machines. Xenon lamp takes the role of changing the electrical energy into luminous one, the laser power is designed by how to light and how to control the discharge of xenon lamp.

    Type

    Outer Diameter/mm

    Arc Length/mm

    Total Length/mm

    LASER

    4

    25

    38

    LASER

    6

    80

    140

    LASER

    6

    70

    130

    LASER

    6

    70

    140

    IPL

    7

    45

    90

    IPL

    7

    50

    110

    IPL

    7

    50

    115

    IPL

    7

    65

    125

    IPL

    7

    65

    135

    LASER

    8

    100

    155

    LASER

    9

    80

    140

    Customized: The regular dimensions are for reference only,if you didn’t find type you are looking for,please feel free to contact us for individual solution.
